Solenoid Valve, 2-Way, 2-Position, Normally Closed, 1/8 in Pipe Size, 24V AC, Compact, Brass, FKM

Description

<p>The ASCO SC8256B045V is a compact, direct-acting 2-way/2-position solenoid valve with a normally closed configuration. The valve is rated to control media: air, inert gases, light oil, and water within the specified operating pressure and temperature ranges. Operation is actuated by an energized coil; coil included with the product. This valve supports both horizontal and vertical mounting orientations and is rated for indoor use with NEMA 4/4X enclosure protection and IP66 ingress protection.</p> <p>Key Features: <ul> <li>- Body Material: Brass</li> <li>- Seal Material: FKM</li> <li>- Nominal Pipe Size: 1/8 in</li> <li>- Center Line Pipe Size: 1-13/16 in</li> <li>- Orifice Diameter: 1/8 in</li> <li>- Valve Design: 2-Way/2-Position</li> <li>- Valve Starting Configuration: Normally Closed</li> <li>- Operating Pressure Differential Maximum: 135 psi air/inert gas, 80 psi light oil, 126 psi water</li> <li>- Operating Pressure Differential Minimum: 0 psi for air/inert gas, light oil, and water</li> <li>- Fluid Temperature Maximum: 180°F</li> <li>- Coil Voltage: 24V AC</li> <li>- Coil Wattage: 6.3 W</li> <li>- Coil Insulation Class: F</li> <li>- Electrical Connections: DIN</li> <li>- Coil enclosure without a junction box; enclosure rated watertight per product specifications</li> <li>- Includes Coil: Yes</li> <li>- Includes Seal: Yes</li> <li>- Environmental Rating: Indoor</li> <li>- Response Time: 20 msec</li> <li>- Overall Dimensions: Length 1-13/16 in, Height 2 in, Width 1 in</li> </ul></p>
