IEC Magnetic Contactor, No Auxiliary Contacts, 24V AC, 4 P, Non-Reversing

Description

<p>The DAYTON - IEC Magnetic Contactor is a non-reversing, 4-pole device with no auxiliary contacts. It operates on a coil voltage of 24V AC and has a frequency of 50/60 Hz. This contactor is designed to handle full load amps-inductive of 12 A and full load amps-resistive of 25 A. The compact design measures an overall depth, height, and width each at 1.77 inches.</p> <p>Key features include: <li>- Non-reversing action: This means the contactor does not have the capability to reverse its direction.</li> <li>- No Auxiliary Contacts: There are no additional contacts for supplementary functions.</li> <li>- Coil Voltage: Operates on a standard electrical current of 24V AC.</li> <li>- Full Load Amps: Rated for inductive loads of 12A and resistive loads of 25A.</li> <li>- Compact Size: With dimensions all measuring at approximately less than two inches, it can fit into tight spaces easily.</li> <li>- Horsepower Ratings: Compatible with devices having horsepower ratings within the range of one hp @ single phase -120V AC to two hp @ single phase -240V AC.</li> <li>- Main Contact Configuration: Features special main contact configuration with two normally closed (2NC) and two normally open (2NO) main contacts.</li> <li>-Standards Compliance: Complies with CSA and UL Listed standards as per North American safety regulations.</li></p>
