IEC Magnetic Contactor, No Auxiliary Contacts, 120V AC, 4 P, Non-Reversing, Screw

Description

<p>The IEC Magnetic Contactor is a non-reversing, 4-pole control device with a 120 V AC coil and a 50/60 Hz rating. It has no auxiliary contacts and no embedded surge suppressor, and it is rated for operation without an enclosure (if applicable) or no enclosure is provided. This configuration supports standard IEC applications where standardized sizing and interchangeability are preferred.</p> <p>- Item: IEC Magnetic Contactor</li> <li>- Action / Reversing: Non-Reversing (Reversing: No)</li> <li>- Poles: 4</li> <li>- Main Contact Configuration: 2NC/2NO</li> <li>- Auxiliary Contacts: No</li> <li>- Coil Voltage: 120 V AC</li> <li>- Frequency: 50/60 Hz</li> <li>- Full Load Amps: Inductive 25 A, Resistive 40 A</li> <li>- HP @ 120V / 230V / 240V: 2 hp; 3 hp; 3 hp</li> <li>- Dimensions: Height 2.2 in, Width 2.2 in, Depth 3.75 in</li> <li>- Enclosure / NEMA: No Enclosure</li> <li>- Standards: CSA, UL Listed</li> <li>- Terminal Connection Type: Screw</li></ul></p>
