IEC Magnetic Contactor, 1NO, 240V AC, 3 P, Non-Reversing, Screw

Description

<p>The DAYTON IEC Magnetic Contactor is an IEC-standard, electrically operated switch rated for switching within specified electrical parameters. It is a 3-pole device with a 240 V AC coil, operates with non-reversing functionality, and screw terminals, featuring one normally open auxiliary contact.</p> <p>- Action: operates with non-reversing functionality</li> <li>- Poles: 3</li> <li>- Coil Voltage: 240 V AC</li> <li>- Auxiliary Contacts: 1 NO (Auxiliary Contact Form: 1NO)</li> <li>- Embedded Surge Suppressor: No</li> <li>- Frequency: rated for operation at 50/60 Hz frequencies</li> <li>- Full Load Amps: rated for continuous operation at specified current ratings under typical load conditions (Inductive 25 A / Resistive 40 A)</li> <li>- HP Ratings: rated for use with motors up to the specified horsepower ratings at corresponding voltages (120 V: 2 hp; 230 V: 3 hp; 240 V: 3 hp; 208 V: 5 hp; 240 V: 7.5 hp; 480 V: 15 hp; 575 V: 20 hp)</li> <li>- Dimensions: 2.2 in W × 2.2 in H × 3.75 in D</li> <li>- Standards: CSA, UL Listed</li> <li>- Terminal Connection Type: Screw</li> <li>- Reversing: No</li></ul></p>
