Locking Plug, Non-NEMA, 30 A, 250V AC, Single Phase, 2 Pole, Screw Terminals, Black, White

Description

<p>The HUBBELL 30A Locking Plug is an industrial electrical connector rated for use in specified applications and environments. This locking plug features a ribbed nylon housing; see specifications for material properties, as well as a cord grip design intended to reduce strain on wire terminations. The clear, funnel-shaped wire entry facilitates wiring process, while an integral dust shield over the wiring chamber helps keep contaminants out.</p><br /><br /><p>Key Features of the HUBBELL 30A Locking Plug:<br><br /></p><ul><br /><li>Amperage/Voltage Rating: Rated for 30 A and 250V AC single-phase applications</li><br /><li>Poles/Wires: 2-pole, 3-wire configuration with screw terminal connections</li><br /><li>Cable Range: Accepts cable diameters from 0.360" to 0.930"; accommodates #16 AWG to #8 AWG stranded copper wire</li><br /><li>Housing Material: Nylon construction provides chemical and impact resistance; ribbed exterior enhances grip</li><br /><li>Cord Grip Design: Protects against excess strain on terminations during use</li><br /><li>Wire Entry &amp; Dust Shield: Funnel-shaped entry aids termination; integrated dust shield over the wiring chamber helps keep contaminants out</li><br /><li>Operating Temperature Range: Suitable for continuous operation from -40°C (without impact) up to +75°C</li><br /><li>Flammability &amp; Dielectric Strength: Meets HB or better per UL94; withstands dielectric voltages up to 2,000V minimum</li><br /><li>NEMA Configuration/IP Rating: Non-NEMA plug type with IP20 suitability (indoor dry locations unless otherwise protected)</li><br /><li>Standards Compliance: Certified to CSA C22.2 No.42, Federal Specification W-C-596, and listed to UL498 standards</li></ul><p>&nbsp;</p>
