Solenoid Valve, 2-Way, 2-Position, Normally Closed, 1/8 in Pipe Size, 120V AC, Compact, FKM

Description

<p>The ASCO U8256A014V is a direct-acting, normally closed compact solenoid valve designed to control the flow of air, inert gas, light oil, and water. Constructed with a stainless steel body and FKM seals, it supports both horizontal and vertical mounting orientations. The valve is rated for operation with air, inert gas, light oil, and water; actuation is via an electrical coil with 18-inch leads, with operation limited to the specified maximum differential pressures. It operates at 120V AC and 60 Hz frequency and is rated for indoor environments with NEMA 4 and 4X enclosure protection.</p> <p>Key Features: <ul><li>- Valve Design: 2-Way/2-Position, Normally Closed</li> <li>- Body Material: Stainless Steel</li> <li>- Seal Material: FKM</li> <li>- Nominal Pipe Size: 1/8 in with NPTF inlet and outlet connections</li> <li>- Orifice Diameter: 19/32 in; Coefficient of Volume (Cv): 0.08</li> <li>- Maximum Operating Pressure Differential: 400 psi (Air/Inert Gas), 230 psi (Light Oil), 390 psi (Water)</li> <li>- Coil Enclosure: Open Frame with Class F insulation</li> <li>- Electrical Specifications: 120V AC, 6.3 W power consumption, 18 in Leads</li> <li>- Response Time: 20 milliseconds</li> <li>- Dimensions: 2 in height, 1-13/16 in length, 1 in width</li> <li>- Environmental Rating: Indoor; NEMA Enclosure Rating: 4, 4X; IP Rating: 66</li></ul></p>
